Interface：Female connectors
Input：100V-240V
Output：5V/1A+5V/11.5A
Power：62.5W
Dimension：130*155*31mm
Weight：302g
Output Characteristics：5V/1A；5V/11.5A；12V/1A
Protect Function：open-loop overvoltage protection,overcurrent protection,overvlotage protection,overtemperature protection
Applicable Environment：used for shared power cabinet and works under 0-40℃ environment
Certification Scope：Obtained CE,CB,CQC certificates bundled with shared power cabinet together
產品詳情
1.The 5V main output can charge for 6 channels power bank;
2.The 5V main output can be used for driving motors after raised voltage to 12V by DC-DC booster
3.Provide independent 5V/1A output for system power supply.
